ADBOX-P701 série Agrandir l'image

ADBOX-P701-C2

ADBOX-P701-C2

PC box industriel sans ventilateur, Intel Celeron 3865U, port standard, 2 PCI, 2 LAN Gigabit, mémoire 16GB, VGA, USB, RST, COM, 9 à 36V DC, -10 à 50 °C

Plus de détails

Documentation

En savoir plus

► ADBOX-P701 série
► Boîtier aluminium pur, couleur personnalisable
► CPU Intel Celeron 3865U (double coeur, 2MB second cache, 1.8 GHz) ; Intel Core i5 7200U (double coeur, 2.5GHZ, turbo boost 3.1GHZ, TDP: 15W)
► RAM 1 slot mémoire DDR4 1866/2133, 16GB max
► Carte graphique Intel HD 620 intégrée
► Affichage 1 VGA (can exact another one HDMI port)
► E/S avant : 2 USB3.0, 2 USB2.0, 2 Indicateurs Led, 1 bouton d'alimentation
► E/S arrière : 2 USB3.0, 2 COM (2 COM RS232/422/485), 2 ports LAN Intel 1000M, 1 VGA, 1 connecteur phoenix, 1 RST
► Supporte 1 mini PCIE (WIFI/3G/4G Optionnel), slot SIM, 1 mini PCIE (pour mSATA)
► GPIO optionnel (standard non inclus), 2 ports LAN Intel i211-AT 10/100/1000M
► 1 2.5" SATA, 1 MSATA
► Support 1 MSATA, 1 HDD 2.5"
► Prise en charge de la réinitialisation matérielle (niveau 256 ~ 0 ~ 255 sec)
► Prise en charge d'une tension large 9 - 36V DC
► Températures -10 à 50 °C

Modèles disponibles :

► Configuration 1 : ADBOX-P701-C1 - Intel Celeron 3865U, Standard Port, 1 PCIE 4X + 1 PCI
► Configuration 2 : ADBOX-P701-C2 - Intel Celeron 3865U, Standard Port, 2 PCI
► Configuration 3 : ADBOX-P701-C3 - Intel Core i5 7200U, Standard Port, 1 PCIE 4X + 1 PCI
► Configuration 4 : ADBOX-P701-C4 - Intel Core i5 7200U, Standard Port, 2 PCI

Caractéristiques

Ports LAN2 ports
Ports USBOui
GigabitOui
Interface Série2 ports COM
Alimentation9-36V DC
Températures-10 à 50 °C
SIM1
IndustrielOui
CPUCeleron 3865U
Bus2 PCI
SATAmSATA
Interface VGAOUI
